FTD Dentifix-3D HR 3D Printing Resin
FTD Dentifix-3D HR 3D Printing Resin
Fun To Do 3D printing resin for dental models, DLP/LCD compatible. 2 colors available.
3D Printing resin Fun To Do Dentifix-3D High Reactivity.
A new resin for dental models by Fun To Do.
A resin born from the collaboration of Fun To Do with professionals from the dental field.
The resin has a very smooth surface after printing and a great hardness that makes it ideal for dental models creation.
Its matt beige color makes details clear and facilitates laboratory work by eliminating annoying reflexes. Also available in matt grey.
This HR resin, High reactivity, is compatible with DLP (ex. Lumiforge) or LCD printers (ex. Wanhao/Photon/LumiCube).
3D printing resin Fun To Do Dentifix-3D HR characteristics
Package | 1kg | |
Applications | Dental models | |
Color | Opaque, Sand Yellow RAL 1002 / Grey | |
Viscosity | at 25°C | 95 mPa.s |
Hardness (Shore D) | 81 | |
Exposure Energy | 18 mJ/cm2 | |
Max. cure depth | 0.085 | |
Resolution | 0.02-0.085 mm | |
Tensile strenght | 45 Mpa | |
Elongation at break | 5% | |
Shrinkage | <0.2% |
Although the properties in this table are accurate, Dentifix-3D can't make any warranty, expressed or implied regarding the accuracy of the properties obtained by the use of this product.
Product properties can change without any prior notice.
Finishing Instructions
To clean and remove excess resin, agitate the 3D printed part in an ulkltrasonic cleaner with TEK1969 cleaning or in a simple vat with TEK1960 solvent* for 1-2 minutes until all excess resins has been removed.
Do not soak in acetone. Do not leave the 3D part soaking in the liquid. Use a soft brush if necessary.
Clean off any excess of liquid with a cold blowdryer or compressed air.
Leave under the sun or in a UV lamp to cure. The resin is fully cured when fingernails do not leave scratch marks on the object.
Even after full post cure some parts may still have a sticky surface. You can treat your print with Ta-Tack Away. A quick wash in this special formula will add a stick-free coating on the printed part.Store the resin in a dry, cool, shaded place out of direct sunlight.
*We do not recommend the use of denatured or isopropyl alcohol (IPA). It is very aggressive on the polymerized resin and it could weaken the structure of the 3D part. It is also flammable and potentially harmful to people and the environment.
Store the resin in a dry, cool, shaded place out of direct sunlight.
